Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve

  • 1
  • 2
  • 3

Brand Name : LESER

Model Number : Type 485

Place of Origin : Germany

MOQ : 1 set

Payment Terms : T/T, D/A, L/C, D/P, Western Union

Supply Ability : 50 SETS/MONTH

Delivery Time : 6~8 WEEKS

Packaging Details : Carton

Nominal Diameter at Inlet : DN 25 - DN 40 | 1'' - 2''

Orifice : D - F

Actual Orifice Diameter d₀ : 13 - 25 mm | 0.512 - 0.984 in

Actual Orifice Area A₀ : 133 - 491 mm² | 0.206 - 0.761 in²

Pressure : 0.1 - 16 bar | 1.5 - 232 psig

Temperature (in accordance with DIN EN) : -45 to 250 °C | -49 to 482 °F

Body Material : 1.4435 (BN2) | SA 479 316L

Valve Connection : Inlet: Integrated pipework connection type 5034 for welding into the pipe with welded connection acc. to ISO 2037, DIN 11850 oder DIN EN ISO 1127 Outlet: Clamps acc. to ASME BPE /DIN 32676, ISO 2852 or DIN EN ISO 1127, Aseptic clamp acc. to DIN 11864 T1 Se

Bellows Material (optional) : EPDM

Load Type : Spring loaded

Specials : HyTight Assembly Designed and manufactured acc. to: DIN 11866, ASME BPE, EN 1672-2, DIN ISO 14159, USP class VI and FDA 21 CFR

Contact Now

Type 485 With A low Dead Space Ratio Through Weldable Spring Loaded Safety Valve

Safety valve with small to medium capacities and a low dead space ratio through weldable, integrated pipework connection

Product Description
Specification
item
value
Warranty
1 Year
Type
Safety Relief Valves
Place of Origin
Germany
Brand Name
LESER
Model Number
Type 485
Application
Industries
Structure
Safety
Nominal Diameter at Inlet
DN 25 - DN 40 | 1'' - 2''
Orifice
D - F
Actual Orifice Diameter d
13 - 25 mm | 0.512 - 0.984 in
Actual Orifice Area A
133 - 491 mm² | 0.206 - 0.761 in²
Pressure
0.1 - 16 bar | 1.5 - 232 psig
Temperature (in accordance with DIN EN)
-45 to 250 °C | -49 to 482 °F
Body Material
1.4435 (BN2) | SA 479 316L
Specials
DIN 11866, ASME BPE, EN 1672-2, DIN ISO 14159
Bellows Material (optional)
EPDM
Load Type
Spring loaded
Packing & Delivery
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Safety Valve For Pressure Cooker Type 485 With A low Dead Space Ratio Through Weldable Spring Loaded Safety Valve Spare Parts kits blister packed for quick and easy usage for Tartarini Pressure Reducing Regulators as valv valvpacked with one fumigation wooden box Box size: 60*30*40 (cm) WG:4.5 Kg
Company Profile
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Type 485 With A Low Dead Space Ratio Through Weldable Spring Loaded Safety Valve
Xiangjing (Shanghai) Electromechanical Technology Co., Ltd. is mainly engaged in the technical development, technical consultation, technical service, installation and commissioning services of marine engineering, oil and gas, petrochemical, water conservancy and hydropower, thermal power generation and other mechanical and electrical equipment products; Well-known brand fluid control valves; instrumentation; hydraulic pipe fittings; bearings; seals; industrial automation and other high-tech enterprises. With our dedicated service, our customers' work is made easy and efficient. As a comprehensive supplier of electromechanical products, Xiangjing (Shanghai) Technology Co., Ltd. adheres to the modern market concept of customer-centered, relying on the rich product resources of the Doctoral Group and the industry e-commerce platform and the centralized professional service team to pass professional orders. Procurement, specialized inventory and distribution management and specialized technical support to achieve accurate and timely delivery services, localized services and quick and timely response, maximizing customer value, effectively shortening your spare parts supply cycle and effectively reducing inventory Effectively improve the efficiency of your work, thus effectively improving the overall competitiveness of the company.
